Input: DC12V/3A Adapter
Outputs: DC9V/500mA *4
DC9V/200mA *4
DC6/9V-200mA *1 (switch on to get DC 9V)
DC9/12V-200mA *1 (switch on to get DC 12V)
DC9/15V-200mA *1 (switch on to get DC 15V)
DC9/18V-200mA *1 (switch on to get DC 18V)
Dimensions: 19.7*8.1*2.3(cm)
Output Power：36W
Accuracy：3%
Body Weight:368g
A short-circuit protection circuit design for each output. An IC with short-circuit protection function for each output. When any single or more output occurs short circuit, output will be quickly cut off, corresponding red LED light will be off to help users quickly find out fault points. When the fault is eliminated, the red LED light will be on. Along with this process, the other output will not be affected. These ensure the safety of the music equipment and the stability of the playing.
